Customized forklift clamp accessories and carton clamp of various sizes

Parameter

Product Description

CCS20D-006A Opening Range 560-1930mm, Arm Height 1220mm, Arm Length 1240mm, Vertical Center of Gravity 315mm

CCS20D-007A Opening Range 560-1930mm, Arm Height 1525mm, Arm Length 1370mm, Vertical Center of Gravity 380mm

CCS30D-008B Opening Range 535-1850mm, Arm Height 1525mm, Arm Length 1015mm, Vertical Center of Gravity 450mm

CCS30D-009B Opening Range 535-1850mm, Arm Height 1525mm, Arm Length 1015mm, Vertical Center of Gravity 450mm


Options
* Custom opening ranges
* Various mounting classes available

Remark:

1. Obtain the actual capacity of forklift and accessories from the forklift manufacturer.

2. Two sets of additional oil circuits are required on the forklift.

3. The opening range is the space between the tips of the two arms.

4. All carton clamps are equipped with four tank pressure regulating valves

Other size available on request.


Installation & Option
Hydraulic Flow & Pressure

Options:

* Four position pressure regulating valve.

* Pad up and extend.

* Increase the load on the backrest.

Applicable Industries
Mechanical repair shop, manufacturing factory, catering shop, printing factory

Can be customized according to size
Customized solutions:
1. Carton Clamp
2. Block Clamp
3. Bale Clamp
4. Roll Clamp
......
all kinds of attachment

Bonafe is an enterprise specializing in the research and development, production and sales of series forklift accessories and forklift parts. The company's products include forklift truck accessories, such as soft pack clamps, ejectors, paper roll clamps, fork clamps, drum clamps, tire clamps, steel pipe clamps, rotary pushers, etc. Forklift attachments, and various sizes of forklift attachments can be customized according to customer needs. Forklift parts and various precision machinery parts.

Bonafe has strong technical force. The forklift attachments produced by Bonafe are widely used in chemical fiber, textile, machinery, white goods, papermaking, tobacco, storage and distribution, docks and other materials handling operations. It is an ideal product to replace the traditional forklift single operation. Give full play to the performance advantages of forklifts. Products are exported to Europe, the United States, Southeast Asia and other markets.
